15 - 90 December 2000
The <num> parameter lets you display the table beginning with a specific entry number.
NOTE: The entry numbers in the ARP cache are not related to the entry numbers for static ARP table entries.
This display shows the following information. The number in the left column of the CLI display is the row number
of the entry in the ARP cache. This number is not related to the number you assign to static MAC entries in the
static ARP table.
USING THE WEB MANAGEMENT INTERFACE
To display the IP ARP cache:
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view to list the monitoring options.
3. Click on the ARP Cache
link to display the IP ARP cache.
This display shows the following information.
Table 15.11: CLI Display of ARP Cache
This Field... Displays...
IP Address The IP address of the device.
MAC Address The MAC address of the device.
Type The type, which can be one of the following:
• Dynamic – The Layer 3 Switch learned the entry from an
incoming packet.
• Static – The Layer 3 Switch loaded the entry from the static ARP
table when the device for the entry was connected to the Layer 3
Switch.
Age The number of minutes the entry has remained unused. If this value
reaches the ARP aging period, the entry is removed from the table.
To display the ARP aging period, see “Displaying Global IP
Configuration Information” on page 15-84. To change the ARP aging
interval, see “Changing the ARP Aging Period” on page 15-30.
Note: Static entries do not age out.
Port The port on which the entry was learned.
Table 15.12: Web Display of ARP Cache – Layer 3 Switch
This Field... Displays...
Node The IP address of the device.
MAC Address The MAC address of the device.
