Page #536 background image
Foundry Switch and Router Installation and Configuration Guide
15 - 94 December 2000
This display shows the following information.
Displaying the IP Route Table
To display the IP route table, use one of the following methods.
USING THE CLI
To display the IP route table, enter the following command at any CLI level:
BigIron> show ip route
Total number of IP routes: 514
Table 15.15: Web Display of IP Forwarding Cache Information Layer 3 Switch
This Field... Displays...
IP Address The IP address of the destination.
Next Hop The IP address of the next-hop router to the destination. This field
contains either an IP address or the value DIRECT. DIRECT means
the destination is either directly attached or the destination is an
address on this Foundry device. For example, the next hop for
loopback addresses and broadcast addresses is shown as DIRECT.
MAC The MAC address of the destination.
Note: If the entry is type U (indicating that the destination is this
Foundry device), the address consists of zeroes.
Type The type of host entry, which can be one or more of the following:
D Dynamic
P Permanent
F Forward
U Us
C Complex Filter
W Wait ARP
I ICMP Deny
K Drop
R Fragment
S Snap Encap
Action This information is used by Foundry customer support.
Flag Check This information is used by Foundry customer support.
Snap This information is used by Foundry customer support.
Port The port through which this device reaches the destination. For
destinations that are located on this device, the port number is shown
as n/a.
VLAN Indicates the VLAN(s) the listed port is in.
Priority The QoS priority of the port or VLAN.
