Foundry Networks Switch and Router User Manual

Configuring IP
December 2000 15 - 109
USING THE WEB MANAGEMENT INTERFACE
To display IP traffic statistics:
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration panel is displayed.
2. Click on the plus sign next to Monitor in the tree view to list the monitoring options.
3. Click on the plus sign next to IP to list the IP monitoring options.
4. Click on the Traffic
link to display the table.
This display shows the following information.
Table 15.23: Web Display of IP Traffic Statistics – Layer 2 Switch
This Field... Displays...
IP statistics
Packets Received The number of IP packets received by the device.
Packets Sent The number of IP packets originated and sent by the device.
Fragmented The number of IP packets fragmented by this device before sending
or forwarding them.
Reassembled The number of fragmented IP packets received and re-assembled by
the device.
Bad Header The number of packets dropped because they had a bad header.
No Route The number of packets dropped because they had no route
information.
Unknown Protocols The number of packets dropped because they were using an
unknown protocol.
No Buffer The number of packets dropped because the device ran out of buffer
space.
Other Errors The number of packets dropped due to errors other than the ones
listed above.
ICMP statistics
Total Received The number of ICMP packets received by the device.
Total Sent The number of ICMP packets sent by the device.
Received Errors This information is used by Foundry customer support.
Sent Errors This information is used by Foundry customer support.
Received Unreachable The number of Destination Unreachable messages received by the
device.
Sent Unreachable The number of Destination Unreachable messages sent by the
device.
Received Time Exceed The number of Time Exceeded messages received by the device.
Sent Time Exceed The number of Time Exceeded messages sent by the device.
Received Parameter The number of Parameter Problem messages received by the device.
