Configuring RIP
December 2000 16 - 17
This display shows the following information.
Table 16.3: CLI Display of RIP Filter Information
This Field... Displays...
Route filters
The rows underneath “RIP Route Filter Table” list the RIP route filters. If no RIP route filters are configured on
the device, the following message is displayed instead: “No Filters are configured in RIP Route Filter Table”.
Index The filter number. You assign this number when you configure the
filter.
Action The action the router takes if a RIP route packet matches the IP
address and sub-net mask of the filter. The action can be one of the
following:
• deny – RIP route packets that match the address and network
mask information in the filter are dropped. If applied to an
interface’s outbound filter group, the filter prevents the router
from advertising the route on that interface. If applied to an
interface’s inbound filter group, the filter prevents the router from
adding the route to its IP route table.
• permit – RIP route packets that match the address and network
mask information are accepted. If applied to an interface’s
outbound filter group, the filter allows the router to advertise the
route on that interface. If applied to an interface’s inbound filter
group, the filter allows the router to add the route to its IP route
table.
Route IP Address The IP address of the route’s destination network or host.
Subnet Mask The network mask for the IP address.
Neighbor filters
The rows underneath “RIP Neighbor Filter Table” list the RIP neighbor filters. If no RIP neighbor filters are
configured on the device, the following message is displayed instead: “No Filters are configured in RIP
Neighbor Filter Table”.
Index The filter number. You assign this number when you configure the
filter.
Action The action the router takes for RIP route packets to or from the
specified neighbor:
• deny – If the filter is applied to an interface’s outbound filter
group, the filter prevents the router from advertising RIP
routes to the specified neighbor on that interface. If the filter
is applied to an interface’s inbound filter group, the filter
prevents the router from receiving RIP updates from the
specified neighbor.
• permit – If the filter is applied to an interface’s outbound filter
group, the filter allows the router to advertise RIP routes to
the specified neighbor on that interface. If the filter is applied
to an interface’s inbound filter group, the filter allows the
router to receive RIP updates from the specified neighbor.
Neighbor IP Address The IP address of the RIP neighbor.
