Foundry Switch and Router Installation and Configuration Guide
18 - 20 December 2000
USING THE WEB MANAGEMENT INTERFACE
You cannot display PIM Sparse information using the Web management interface.
Displaying a List of Multicast Groups
To display a list of the IP multicast groups the Layer 3 Switch is forwarding, use the following CLI method.
USING THE CLI
To display PIM Sparse configuration information, enter the following command at any CLI level:
BigIron(config-pim-router)# show ip pim group
Total number of Groups: 2
Index 1 Group 239.255.162.1 Ports e3/11
Syntax: show ip pim group
This display shows the following information.
USING THE WEB MANAGEMENT INTERFACE
You cannot display PIM Sparse information using the Web management interface.
Displaying BSR Information
To display information about the BSR, use the following CLI method.
USING THE CLI
To display BSR information, enter the following command at any CLI level:
BigIron(config-pim-router)# show ip pim bsr
PIMv2 Bootstrap information
This system is the elected Bootstrap Router (BSR)
BSR address: 207.95.7.1
Uptime: 00:33:52, BSR priority: 5, Hash mask length: 32
TTL Threshold Following the TTL threshold value, the interface state is listed. The
interface state can be one of the following:
• Disabled
• Enabled
Local Address Indicates the IP address configured on the port or virtual interface.
This Field... Displays...
Total number of Groups Lists the total number of IP multicast groups the Layer 3 Switch is
forwarding.
Note: This list can include groups that are not PIM Sparse groups. If
interfaces on the Layer 3 Switch are configured for regular PIM
(dense mode) or DVMRP, these groups are listed too.
Index The index number of the table entry in the display.
Group The multicast group address
Ports The Layer 3 Switch ports connected to the receivers of the groups.
This Field... Displays...
