Foundry Switch and Router Installation and Configuration Guide
18 - 24 December 2000
This display shows the following information.
USING THE WEB MANAGEMENT INTERFACE
You cannot display PIM Sparse information using the Web management interface.
Displaying the RP Set List
To display the RP set list, use the following CLI method.
USING THE CLI
To display the RP set list, enter the following command at any CLI level:
BigIron(config-pim-router)# show ip pim rp-set
Number of group prefixes = 1
Group prefix = 224.0.0.0/4 # RPs expected/received: 1
RP 1: 207.95.7.1 priority=0 age=0
Syntax: show ip pim rp-set
This display shows the following information.
USING THE WEB MANAGEMENT INTERFACE
You cannot display PIM Sparse information using the Web management interface.
This Field... Displays...
RP Indicates the IP address of the Rendezvous Point (RP) for the
specified PIM Sparse group.
Following the IP address is the port or virtual interface through which
this Layer 3 Switch learned the identity of the RP.
Info source Indicates the IP address on which the RP information was received.
Following the IP address is the method through which this Layer 3
Switch learned the identity of the RP.
This Field... Displays...
Number of group prefixes The number f PIM Sparse group prefixes for which the RP is
responsible.
Group prefix Indicates the multicast groups for which the RP listed by the previous
field is a candidate RP.
RPs expected/received Indicates how many RPs were expected and received in the latest
Bootstrap message.
RP <num> Indicates the RP number. If there are multiple RPs in the PIM Sparse
domain, a line of information for each of them is listed, and they are
numbered in ascending numerical order.
priority The RP priority of the candidate RP. During the election process, the
candidate RP with the highest priority is elected as the RP.
age The age (in seconds) of this RP-set.
Note: If this Layer 3 Switch is not a BSR, this field contains zero. Only
the BSR ages the RP-set.
