21 - 20 December 2000
Interface VRID CurPri P State Master addr Backup addr VIP
1/6 1 255 P Init 192.53.5.1 192.53.5.3 192.53.5.1
This example is for VRRP. Here is an example for VRRPE:
BigIron Router(config-if-e1000-1/6-vrid-1)# show ip vrrp-extended brief
Total number of VRRP-Extended routers defined: 1
Interface VRID CurPri P State Master addr Backup addr VIP
1/6 1 255 P Init 192.53.5.2 192.53.5.3 192.53.5.254
Syntax: show ip vrrp brief | ethernet <portnum> | ve <num> | stat
Syntax: show ip vrrp-extended brief | ethernet <portnum> | ve <num> | stat
The brief parameter displays the summary information. If you do not use this parameter, detailed information is
displayed instead. See “Displaying Detailed Information” on page 21-21.
The ethernet <portnum> parameter specifies an Ethernet port. If you use this parameter, the command displays
VRRP or VRRPE information only for the specified port.
The ve <num> parameter specifies a virtual interface. If you use this parameter, the command displays VRRP or
VRRPE information only for the specified virtual interface.
The stat parameter displays statistics. See “Displaying Statistics” on page 21-27.
This display shows the following information.
Table 21.2: CLI Display of VRRP or VRRPE Summary Information
This Field... Displays...
Total number of VRRP (or VRRP-
Extended) routers defined
The total number of VRIDs configured on this Layer 3 Switch.
Note: The total applies only to the protocol the Layer 3 Switch is
running. For example, if the Layer 3 Switch is running VRRPE, the
total applies only to VRRPE routers.
Interface The interface on which VRRP or VRRPE is configured. If VRRP or
VRRPE is configured on multiple interfaces, information for each
interface is listed separately.
VRID The VRID configured on this interface. If multiple VRIDs are
configured on the interface, information for each VRID is listed in a
separate row.
CurPri The current VRRP or VRRPE priority of this Layer 3 Switch for the
VRID.
P Whether the backup preempt mode is enabled. If the backup preempt
mode is enabled, this field contains a “P”. If the mode is disabled, this
field is blank.
