21 - 22 December 2000
VRID 1
state backup
administrative-status enabled
mode non-owner(backup)
priority 100
current priority 100
hello-interval 1 sec
dead-interval 3.600 sec
current dead-interval 3.600 sec
preempt-mode true
advertise backup: enabled
backup router 192.53.5.3 expires in 00:00:03
next hello sent in 00:00:02
track-port 3/2
Here is an example for a VRRPE Backup.
BigIron Router(config)# show ip vrrp-extended
Total number of VRRP-Extended routers defined: 1
Interface ethernet 1/6
auth-type no authentication
VRID 1
state master
administrative-status enabled
priority 200
current priority 200
hello-interval 1 sec
dead-interval 3.600 sec
current dead-interval 3.600 sec
preempt-mode true
virtual ip address 192.53.5.254
advertise backup: enabled
master router 192.53.5.2 expires in 00:00:03
track-port 2/4
Syntax: show ip vrrp brief | ethernet <portnum> | ve <num> | stat
Syntax: show ip vrrp-extended brief | ethernet <portnum> | ve <num> | stat
The brief parameter displays summary information. See “Displaying Summary Information” on page 21-19.
The ethernet <portnum> parameter specifies an Ethernet port. If you use this parameter, the command displays
VRRP or VRRPE information only for the specified port.
The ve <num> parameter specifies a virtual interface. If you use this parameter, the command displays VRRP or
VRRPE information only for the specified virtual interface.
The stat parameter displays statistics. See “Displaying Statistics” on page 21-27.
This display shows the following information.
Table 21.3: CLI Display of VRRP or VRRPE Detailed Information
This Field... Displays...
Total number of VRRP (or VRRP-
Extended) routers defined
The total number of VRIDs configured on this Layer 3 Switch.
Note: The total applies only to the protocol the Layer 3 Switch is
running. For example, if the Layer 3 Switch is running VRRPE, the
total applies only to VRRPE routers.
