Foundry Networks Switch and Router User Manual

Configuring VRRP and VRRPE
December 2000 21 - 25
USING THE WEB MANAGEMENT INTERFACE
NOTE: This procedure applies only to VRRP. You cannot display VRRPE information using the Web
management interface.
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration dialog is displayed.
2. Click on the plus sign next to Monitor in the tree view to display the monitoring options.
3. Click on the plus sign next to VRRP in the tree view to expand the list of VRRP option links.
4. Click on the Interface
link to display the virtual router table.
5. Click on the Virtual Router link to display the virtual router table.
NOTE: If a parameter is not defined or does not apply to this type of entry, the field is blank. For example, if the
entry is for a VRRP Owner, the Backup Priority field does not apply and is blank.
This display shows the following information.
next hello sent in <time> How long until the Backup sends its next Hello message.
Note: This field applies only when this Layer 3 Switch is the Master
and the Backup is configured to send Hello messages (the advertise
backup option is enabled).
master router <ip-addr> expires in
<time>
The IP address of the Master and the amount of time until the
Master’s dead interval expires. If the Backup does not receive a Hello
message from the Master by the time the interval expires, either the IP
address listed for the Master will change to the IP address of the new
Master, or this Layer 3 Switch itself will become the Master.
Note: This field applies only when this Layer 3 Switch is a Backup.
track port The interfaces that the VRID’s interface is tracking. If the link for a
tracked interface goes down, the VRRP or VRRPE priority of the
VRID interface is changed, causing the devices to renegotiate for
Master.
Note: This field is displayed only if track interfaces are configured for
this VRID.
Table 21.4: Web Display of VRRP Detailed Information
This Field... Displays...
Interface table
Port The interface number. All the device’s interfaces are listed.
Authentication Type The authentication type enabled on the interface.
Simple Text Password If the authentication type is simple password, this field lists the
password.
Table 21.3: CLI Display of VRRP or VRRPE Detailed Information (Continued)
This Field... Displays...
