Foundry Networks Switch and Router User Manual

Configuring IPX
December 2000 23 - 23
USING THE WEB MANAGEMENT INTERFACE
To display summary IPX traffic statistics:
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration dialog is displayed.
2. Click on the plus sign next to Monitor in the tree view to display the list of monitoring options.
3. Click on the plus sign next to IPX in the tree view to expand the list of IPX option links.
4. Click on the Traffic
link.
This display shows the following information.
To display traffic statistics for each port or virtual interface on which an IPX interface is configured:
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration dialog is displayed.
2. Click on the plus sign next to Monitor in the tree view to display the list of monitoring options.
3. Click on the plus sign next to IPX in the tree view to expand the list of IPX option links.
Transmit The number of IPX packets originated on the Layer 3 Switch and sent
on the port.
Dropped Receive The number of packets received on this port by the Layer 3 Switch
that the Layer 3 Switch dropped.
Dropped Transmit The number of packets queued for sending on this port by the Layer 3
Switch but then dropped.
Filtered Receive The number of packets received by this port that matched an inbound
IPX filter configured on the port.
Filtered Transmit The number of packets queued for sending on this port that matched
an outbound IPX filter configured on the port.
Table 23.7: Web Display of IPX Traffic Statistics
This Field... Displays...
In Packets The number of IPX packets received on the router.
Out Packets The number of IPX packets originated on the router and sent on the
router.
Forwarding Packets The number of IPX packets received by the router from another device
and then sent on the router.
Rcv Drop Packets The number of packets received by the router that the router dropped.
Tx Drop Packets The number of packets queued for sending by the router but then
dropped.
Rcv Filter Packets The number of packets received by the router that matched an
inbound IPX filter.
Tx Filter Packets The number of packets queued for sending that matched an outbound
IPX filter.
Table 23.6: CLI Display of IPX Traffic Statistics (Continued)
This Field... Displays...
