Foundry Networks Switch and Router User Manual

Configuring AppleTalk
December 2000 24 - 19
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-write access.
2. Click on the plus sign next to Configure in the tree view to expand the list of configuration options.
3. Click on the plus sign next to AppleTalk in the tree view to expand the list of AppleTalk option links.
4. Click on the General
link to display the AppleTalk configuration panel.
5. Enter a new AppleTalk ARP Retransmit Interval from 1 – 120 in the ARP Retransmit Interval field. For this
example, enter 15.
6. Click the Apply button to apply the change to the device’s running-config file.
7. Select the Save
link at the bottom of the dialog, then select Yes when prompted to save the configuration
change to the startup-config file on the device’s flash memory
NOTE: You also can access the dialog for saving configuration changes by clicking on Command in the tree
view, then clicking on Save to Flash.
AppleTalk Glean Packets
When you enable the glean packet parameter on an AppleTalk router, the router tries to learn the MAC address
from the packet instead of sending out an ARP request. The glean packets parameter is disabled by default.
EXAMPLE:
To enable glean packets on an AppleTalk router, use one of the following methods.
USING THE CLI
BigIron(config)# appletalk glean-packets
Syntax: appletalk glean-packets
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-write access.
2. Click on the plus sign next to Configure in the tree view to expand the list of configuration options.
3. Click on the plus sign next to AppleTalk in the tree view to expand the list of AppleTalk option links.
4. Click on the General
link to display the AppleTalk configuration panel.
5. Select Enable next to Glean Packet.
6. Click the Apply button to apply the change to the device’s running-config file.
7. Select the Save
link at the bottom of the dialog, then select Yes when prompted to save the configuration
change to the startup-config file on the device’s flash memory.
AppleTalk QoS Socket
You can use the QoS socket parameter to assign a higher priority to specific AppleTalk sockets. Possible values
are 0 (normal priority) to 7 (highest priority) for Chassis devices (including the TurboIron/8). For Stackable
devices, the options are normal or high. The default value for all sockets is normal (Stackable devices) or 0
(Chassis devices).
For more information and procedures, see “Assigning AppleTalk Sockets to Priority Queues” on page 11-26.
AppleTalk RTMP Update Interval
You can change the RTMP update interval to modify how often the router sends RTMP updates on AppleTalk
interfaces. Possible values are from 1 – 3600 seconds. The default is 10 seconds.
