Foundry Networks Switch and Router User Manual

Configuring AppleTalk
December 2000 24 - 21
NOTE: For more details on these commands, see the Foundry Switch and Router Command Line Interface
Reference.
• show appletalk arp cache: Displays the ARP table for the AppleTalk routing protocol.
• show appletalk forward cache:
Displays the forwarding table for the AppleTalk routing protocol.
• show appletalk routing table: Displays the global configuration parameters for the AppleTalk routing
protocol.
• show appletalk zone table:
Displays the network numbers and zones learned on the network.
• show appletalk interface: Displays the AppleTalk configuration for an individual interface or all interfaces.
• show appletalk interface zone: Displays the zones defined on all AppleTalk interfaces.
• show appletalk route: Displays the AppleTalk routing table.
• show appletalk traffic: Displays statistical information for RTMP, ZIP, AEP, DDP and AARP packets.
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration dialog is displayed.
2. Click on the plus sign next to Monitor in the tree view to display the monitoring options.
3. Click on the plus sign next to AppleTalk in the tree view to expand the list of AppleTalk option links.
4. Select one of the following links:
• The ARP Cache
link
• The Forward Cache
link
• The Interface
link
• The Interface Zone
link
• The Routing Table
link
• The Traffic link
• The Zone Table
link
Clearing AppleTalk Information
USING THE CLI
When using the CLI, you can clear AppleTalk data by entering the following CLI commands:
• clear appletalk arp cache: Erases all data in the AppleTalk ARP table, as displayed by the show appletalk
arp command.
• clear appletalk forward cache: Erases all learned data from non-local networks that is currently resident in
the AppleTalk cache (forwarding table), as displayed by the show appletalk cache command.
• clear appletalk route: Erases all learned routes and zones (non-local routes and zones) currently resident in
the AppleTalk routing table, as displayed by the show appletalk route command.
• clear appletalk statistics: Erases all RTMP, ZIP, AEP, DDP, and AARP statistics for the router. You can
display a summary of the statistics that will be erased by entering the show appletalk traffic command.
NOTE: For more details on these commands, see the Foundry Switch and Router Command Line Interface
Reference.
