Saving settings as a job
General The "Store as job" function can be performed in the following menu items:
- MIG/MAG synergic welding
- CC/CV mode
- Job welding
- Optimizing & managing jobs
Instructions on
storing jobs
Set all parameters in all screens displayed
– Set parameters in screen A
– Set parameters in screen B
– Set parameters in Screen C, etc.
Press F1 "Store as job" and follow the menu
Store as job Procedure for when certain parameter settings are to be stored as a job:
"Store as job - Group" screen: no. 6 <Empty group>
selected
In the corresponding "Data" screen,
press F1 "Store as job"
– The 1st screen in the wizard appe-
ars ("Store as job - Group")
Select corresponding group using the
adjusting dial (18)
Press F3 "Name group" to name the
group:
– "Name group" screen appears
"Name group" screen
Select corresponding characters using
the adjusting dial (18)
Press F4 ">" to enter the next charac-
ter
– Corrections can be carried out by
pressing F3 "<" or F2 "< Delete".
Press F1 "Accept" when finished:
– The new name is accepted, "Store
as job - Group" screen appears
1
2
1
2
3
4
5
6
