7-2 SPARC Enterprise M4000/M5000 Servers Service Manual • December 2010
FIGURE 7-1 shows the locations of the power supply unit on the M4000 server.
FIGURE 7-1 M4000 Server Power Supply Unit Locations
Location Number Component
1 Power supply unit (PSU#0)
2 Power supply unit (PSU#1)
1
2
To Next Page
