Fujitsu SPARC Enterprise M5000

Chapter 7 Power Systems Replacement 7-3
FIGURE 7-2 shows the locations of the power supply units on the M5000 server.
FIGURE 7-2 M5000 Server Power Supply Unit Locations
Location Number Component
1 Power supply unit (PSU#0)
2 Power supply unit (PSU#1)
3 Power supply unit (PSU#2)
4 Power supply unit (PSU#3)
1
2
3
4
