DIRECTION 5936427, REV. 1 LOGIQ TOTUS Basic Service Manual
8 - 100 Section 8-7 - Replacing OPIO
8-7-10-3 Installation Procedure
1.) Parts to be installed in reverse order of removal
2.) Perform “Functional Checks after FRU replacement (Debrief Guideline)” as described in Section 8-
12 on page 8-223
4.
Lift the UOPIO-T Assy and release the Unity
HDMI Holder Spring and disconnect the cable
from the UOPIO-T Assy.
Step Corresponding graphic
