DIRECTION 5936427, REV. 1 LOGIQ TOTUS Basic Service Manual
8 - 194 Section 8-11 - Replacing Options
8-11-9-2 Removal Procedure
8-11-9-3 Installation Procedure
1.) Parts to be installed in reverse order of removal
2.) Perform “Functional Checks after FRU replacement (Debrief Guideline)” as described in Section 8-
12 on page 8-223
Step Corresponding graphic
1.
Unscrew 2 screws to remove the bracket from the T2 A/N
Keyboard.
2. Release 4 snap fits to remove the latch CP-573 from the bracket.
3.
Unscrew 4 screws to remove latch CP-573S-1 from the T2 A/N
Keyboard.
