124
• Chassis ears with VGA and USB 2.0 connectors.
• Chassis ears without connectors.
NOTE:
The replacement procedure is the same for the two types of left chassis ears except that you must
remove the VGA and USB 2.0 cable and the chassis-open alarm module when you remove a left
chassis ear with connectors. The subsequent procedures use the left chassis ear with VGA and
USB connectors as an example.
Removing the left chassis ear
1. Power off the server. For more information, see "Powering off the server."
2. Remove the server from the rack. For more information, see "Removing the server from a rack."
3. Remove the
access panel. For more information, see "Removing the access panel."
4. Remove the
chassis air baffle. For more information, see "Removing air baffles."
5. Remove the f
an cage. For more information, see "Replacing the fan cage."
6. Remove the
chassis-open alarm module. For more information, see "Replacing the
cha
ssis-open alarm module."
7. Remove the left chassis ear. The removal procedure is the same for the left and right chassis
ears. For more information, see "Removing the right chassis ear."
Installing the left chassis ear
1. Install the left chassis ear. The installation procedure is the same for the left and right chassis
ears. For more information, see "Installing the right chassis ear."
2. Connect the VGA and USB 2.0 cable to the chassis-open alarm module, front VGA, and USB
2.0 connector on the system board. The connection procedure is the same for the VGA and
USB 2.0 cable and the front I/O component cable assembly. For more information, see
"Installing the right chassis ear."
3. Install the chassis-open alarm module. For more information, see "Installing the chassis-open
alarm mo
dule."
4. Install the fan cage. For more information, see "Replacing the fan cage."
5. Install the ch
assis air baffle. For more information, see "Installing air baffles."
6. Install the access panel. For more information, see "Installing the access panel."
7. Rack-mount the server. For more information, see "Rack-mounting the server."
8. Con
nect the power cord. For more information, see "Connecting the power cord."
9. Powe
r on the server. For more information, see "Powering on the server."
