96-8100 1-15-96
32
ALARMS
HAAS AUTOMATION, INC.
SERVICE
MANUAL
VF-SERIES
248 Number Range Error Number entry is out of range.
249 Prog Data Software Error; Call your dealer.
Begins Odd
250 Program Data Error Same as 249.
251 Prog Data Struct Error Same as 249.
252 Memory Overflow Same as 249.
257 Program Data Error Same as 249.
258 Invalid DPRNT Format Macro DPRNT statement not structured properly.
259 Bad Language Version Call your dealer.
260 Bad Language CRC Indicates FLASH memory has been changed. Call your dealer.
261 Rotary CRC Error Rotary table saved parameters (used by Settings 30, 78) have a CRC error. Indicates a loss of
save memory - call your dealer.
262 Parameter CRC Missing RS-232 or floppy read of parameter had no CRC when loading from floppy or RS-232.
263 Lead Screw CRC Missing Lead screw compensation tables have no CRC when loading from floppy or RS-232.
264 Rotary CRC Missing Rotary table parameters have no CRC when loading from floppy or RS-232.
302 Invalid R In G02 or G03 Check your geometry with the HELP page. R must be less than or equal to half the distance
from start to end within an accuracy of 0.0010 inches.
303 Invalid X, Y, or Z In Check your geometry with the HELP page.
G02 or G03
304 Invalid I, J, or K In Check your geometry with the HELP page. Radius at start must match
G02 or G03 radius at end of arc within 0.0010 inches.
305 Invalid Q In Q in a canned cycle must be greater than zero.
Canned Cycle
306 Invalid I, J, K, or Q In I, J, K, and Q in a canned cycle must be greater than zero.
Canned Cycle
307 Subroutine Subprogram nesting is limited to nine levels. Simplify your program.
Nesting Too Deep
309 Exceeded Max Feed Rate Use a lower feed rate.
310 Invalid G Code G code not defined and is not a macro call.
311 Unknown Code Possible corruption of memory by low battery. Call your dealer.
