Page #33 background imageLoading...
Page #33 background image
1-15-96 96-8100
HAAS AUTOMATION, INC.
33
TABLE OF CONTENTS
ALARMS
SERVICE
MANUAL
VF-SERIES
312 Program End End of subroutine reached before M99. Need an M99 to return from subroutine.
313 No P Code In M97, Must put subprogram number in P code.
M98, or G65
314 Subprogram or Macro Check that a subroutine is in memory or that a macro is defined.
Not In Memory
315 Invalid P Code In The P code must be the name of a program stored in memory without a
M97, M98 or M99 decimal point for M98 and must be a valid N number for M99.
316 X Over Travel Range X-axis will exceed stored stroke limits. This is a parameter in negative direction and is machine
zero in the positive direction. This will only occur during the operation of a users program.
317 Y Over Travel Range same as 316.
318 Z Over Travel Range same as 316.
319 A Over Travel Range Not normally possible with A-axis.
320 No Feed Rate Specified Must have a valid F code for interpolation functions.
321 Auto Off Alarm A fault turned off the servos automatically; occurs in debug mode only.
322 Sub Prog Without M99 Add an M99 code to the end of program called as a subroutine.
324 Delay time Range Error P code in G04 is over 1000.0 or over 9999.
325 Queue Full Control problem; call your dealer.
326 G04 Without P Code Put a Pn.n for seconds or a Pn for milliseconds.
327 No Loop For M L code not used here. Remove L Code.
Code Except M97, M98
328 Invalid Tool Number Tool number must be between 1 and 16.
329 Undefined M Code That M code is not defined and is not a macro call.
330 Undefined Macro Call Macro name O90nn not in memory. A macro call definition is in parameters and was accessed
by user program but that macro was not loaded into memory.
331 Range Error Number too large.
332 H and T This alarm is generated when Setting 15 is turned ON and an H code
Not Matched number in a running program does not match the tool number in the spindle. Correct the Hn
codes, select the right tool, or turn off Setting 15.
333 X-axis Disabled Parameters have disabled this axis. Not normally possible in VF Series CNC Mill.
334 Y-axis Disabled same as 333.
