Microlab
®
STAR Service Manual
6-20
Adjusting Pipetting Arm (continued)
Attention: Guides in X and Y Direction must not be bent and must ensure a parallel
movement to the corresponding axis.
The two box section frames of Pipetting Arm, which are the reference to the guides
in Y-Direction, must also be straight and parallel together.
Ensure a proper mounting onto its X slides.
