Microlab
®
STAR Service Manual
6-39
Pipetting Channel Positioning Check (continued):
The goal is to have all LLD sensor
statuses at 0. This means all Low
Volume Tips are absolutely
concentrically positioned and have
therefore no electronic contact with the
calibration tool.
Here in the example only Channel 2
actually passed the check procedure.
6.7 Pressure adjustment values of TADM (ML STAR IVD)
Connect the tubing of the pressure
transmitter as shown to the ML STAR
IVD tip waste.
Connect the RS 232 Cable to the
Computer (any Port) where the Service
software is installed.
PIP_PRESSURE_SIGNALS_CHECK.M
CR
