Hamilton Microlab STAR - Cables; Location of Cables; Cables Part List

Microlab
®
STAR Service Manual
8-22
8.6 Cables
Cables are generally replaced in their previous position. If necessary fold the new
cable to fit.
8.6.1 Location of cables
Refer to the block diagrams in this chapter.
8.6.2 Cables Part list
P/N Description SPC
146355 CABLE W65 A
173817 CABLE X-ARM - PCHN BOARD A
173849 CABLE X-MOVEMENTS A
173850 CABLE FILTER-POWER SUPPLY A
173851 CABLE POWER SUPPLY-40VDC A
173852 CABLE POWER SUPPLY-GND A
173853 CABLE POWER-MASTER A
173854 CABLE POWER-AUTO LOAD A
173858 CABLE SSC A
173863 CABLE DM X-DRIVE PIPETTING ARM A
173890 CABLE POWER SUPPLY-EARTH A
173891 CABLE EC AUTO LOAD X-POSITION A
173898 CABLE RS232 A
173905 CABLE X-ARM CONNECTOR 8C A
173906 CABLE X-ARM CONNECTOR 16C A
173911 CABLE FILTER-EARTH A
182820 CABLE MASTER-EXTENSIONS A
355130 CABLE USB TYPE A-B 3M A
Mains cables for different countries:
P/N Description SPC
235062 POWER CABLE GB C
355008 POWER CABLE SWISS C
355009 POWER CABLE US C
355010 POWER CABLE GERMANY, FRANCE C
