Hamilton Microlab STAR - Main Components; Replacement; Pipetting Arm Replacement Frame P;N 182108

Microlab
®
STAR Service Manual
7-19
7.5.2 Main Components
• Pipetting Arm Replacement Frame P/N 182108
• A & B Channels
• Pipetting Heads 300 µl
• Pipetting Heads 1000 µl
• iSwap
17
7.5.3 Replacement
Preliminary tasks:
• Uncover Pipetting Arm and remove all Pipetting Channels and iSwap (if
installed). Refer to section 7.7 Pipetting Channels on page 7-26.
Attention: store and handle Pipetting Channels and iSwap (if available) with care.
Remove left deck panel - see section 7.4.2 Deck Panels on page 7-7.
For the following removals Refer to section 7.6 Pipetting Arm X-Drive on page 7-23.
• X-Drive Flag P/N 173608
• Pipetting Arm belt claw P/N 173606
• Pipetting Arm measurement carrier P/N 173605. Disconnect Cable first.
Attention: Do not bend or kink X-Movement Cable.
• Unscrew 8 fixing screws (P/N 400047) from carriage main guide in the back, and
then carefully remove Pipetting Arm from instrument.
Note: the 8 fixing screws may occur as setscrews with hex nuts and washers.
Setscrew P/N 405092, hex nut P/N 173459, washer P/N 173458.
17
