Hamilton Microlab STAR - Part List

Microlab
®
STAR Service Manual
7-22
7.5.4.1 Part List
P/N Description SPC
173239 CABLE GUIDE COMPLETE C
173357 Y-FLAG C
173490 ROLL HOLDER C
173491 GUIDE C
173536 REINFORCING ANGLE BRACKET C
173537 PAWL C
173538 PROTECTIVE RING C
173549 GAP DISC C
173823 PIPETTING ARM CONNECTOR A
254087 O-RING ID8.00X2.00 NIT 70SH C
256141 PRESSURE SPRING A
281281 TRACK ROLLER D=16 B
281457 BUTTON BUFFER D=12 F=4 d=8 C
361004 CABLE GUIDE CFCC-4 ½" A
400002 CYL-SCR M3X6 DIN912 A
400026 CYL-SCR M4X12 A
400028 CYL-SCR M4X16 DIN912 A
420561 TORX SCREW M5x12 A
511006 LOCTITE 222 A
Attention: Remove or replace only those Parts which are labeled as Spare Parts.
The Pipetting Arm Replacement Assembly is an adjusted assembly which is not
intended to be serviced in the field, so do not loosen any screws or parts which are
not labeled on the drawing.
