Hamilton Microlab STAR - Microlab STAR Service Kit; Parts

Microlab
®
STAR Service Manual
12-33
12.5 Appendix E
12.5.1 Microlab
®
STAR Service Kit
All items listed below come in the Microlab
®
STAR Service Kit P/N 173970.
Note: The Service Kit Microlab
®
STAR contains items such as parts and Tools.
12.5.1.1 Parts
P/N Description Quantity Spare Part
class
146355 FAME CABLE W65 1 A
173293 STOP HOOK 20 A
173300 DISC 10 A
173310 GREASE 100 GR TOPAS AK50 1 A
173330 TIP EJECTOR 16 A
173332 STOP DISK 16 A
173520 U-DISC 2 16 A
173600 SLIDE BLOCK 30 A
173602 SLIDE BLOCK WEDGE 15 A
173817 CABLE X-ARM -PCHN BOARD 16 A
173823 PIPETTING ARM CONNECTOR 1 A
173833 CARRIER SENSOR BOARD 1 A
173835 POWER DISTRIBUTION BOARD 1 A
173843 LOAD DISPLAY BOARD 1 A
173845 LOAD X-CONNECTOR 1 A
173849 CABLE X-MOVEMENTS 2 A
173850 CABLE FILTER-POWER SUPPLY 1 A
173851 CABLE POWER SUPPLY-40VDC 1 A
173852 CABLE POWER SUPPLY-GND 1 A
173854 CABLE POWER-AUTO LOAD 1 A
173856 OS AUTO LOAD X-INIT 1 A
173858 CABLE SSC 2 A
173860 HS COVER CONTROL 1 A
173863 CABLE DM X-DRIVE PIP ARM 1 A
173864 OS PIPETTING ARM – X-INIT 1 A
173874 DM ROTATE DRIVE 1 A
173875 HS H/V POSITION 2 A
173877 HS LOAD DETECT 1 A
173878 OS TUBE DETECT 1 A
173881 MASTER BOARD PROG 1 A
173882 AUTO LOAD BOARD PROG. 1 A
173890 CABLE POWER SUPPLY-GND 1 A
173891 CABLE EC AUTO LOAD X-POS 1 A
173895 EC PIPETTING ARM X-POSITION 1 A
173898 CABLE RS232 1 A
