7-7
7.4.2 Deck Panels
7.4.2.1 Part List
P/N Description SPC
173378 CAP C
173288 CONTACT PLATE C
173600 SLIDE BLOCK A
173602 SLIDE BLOCK WEDGE A
173833 CARRIER SENSOR BOARD A
173858 CABLE SSC A
182114 REPLACE. DECK AL RIGHT C
182115 REPLACE. DECK AL LEFT C
182118 REPLACE. CARRIER STOP C
182283 DOCKING STATION FOR ML STAR C
400302 CYL-SCR M4X8 DIN912 A2 A
403491 C-SUNK SCR M 4X8 DIN7991 A
420010 CYL-SCR M2,5X8 DIN912 A4 A
420074 CYL-SCR M4X16 DIN912 A2 A
Deck Panels left and right
