Microlab
®
STAR Service Manual
12-42
12.6.10 Autoload Part List
P/N Description SPC
173297 PINION MXL Z=32 C
173845 LOAD X – CONNECTOR A
173849 CABLE X-MOVEMENTS A
173874 DM ROTATOR DRIVE A
173875 HS H/V POSITION A
173877 HS LOAD DETECT A
173878 OS TUBE DETECT A
173879 SCANNER B
182107 REPL. AUTO LOAD DRIVE C
182119 REPL. GUIDE ROLLER C
182120 REPL. RIBBON C
182263 BLACK COVER RIGHT C
182264 BLACK COVER LEFT C
182266 COVER LEFT C
182274 COVER RIGHT C
250016 BALL BEARING ID=6 OD=13/15 C
258140 COG BELT MXL Z= 90X3/16" A
281401 COVERING CAP A
400262 SCREW M3X6 A
403452 SUNK SCREW M3X6 DIN7991 A
403453 SUNK SCREW M3X8 A
403499 SUNK SCREW M4x30 A
409200 DISC M3 A
12.6.11 Autoload's X Drive Part List
P/N Description SPC
173855 SM Auto Load X-Drive C
173856 OS Auto Load X-Init C
250016 BALL BEARING ID=6 OD=13/15 C
250045 BALL BEARING ID=15 OD=35 C
258053 COG BELT MXL Z= 83 X 3/16" A
258134 COG BELT 10T2.5 3065 A
400640 CYL-SCR M4x10 DIN912 TUFLOK A
400653 CYL-SCR M3X6 DIN912 A2 TUFLOK A
405445 SET SCR M3x8 DIN916 A
413005 LOCK DISC 4 DIN6799 A
420580 CYL-SCR M4X50 DIN912 TUFLOK C
