Microlab
®
STAR Service Manual
12-40
Pipetting Arm Part List (continued)
P/N Description SPC
400012 CYL-SCR M3X30 DIN912 A
400024 CYL-SCR M4X8 A
400047 CYL-SCR M5X16 DIN912 A
400604 CYL-SCR M2x8 DIN912 A
400617 CYL-SCR M2.5X5 DIN912 A
400621 CYL-SCR M2.5X12 A
403491 SUNK SCREW M4X8 A
408006 HEX SCREW M 4 DIN934 A
420013 CYL-SCR M3X8 DIN912 A
511071 OMNI FIT 15M A
7279372 ADHESIVE TAPE 1-SIDED D=2 B=12 A
12.6.6 Replacement Frame Pipetting Arm P/N 182108 Part List
P/N Description SPC
173239 CABLE GUIDE COMPLETE C
173357 Y-FLAG C
173490 ROLL HOLDER C
173491 GUIDE C
173536 REINFORCING ANGLE BRACKET C
173537 PAWL C
173538 PROTECTIVE RING C
173549 GAP DISC C
173823 PIPETTING ARM CONNECTOR A
254087 O-RING ID8.00X2.00 NIT 70SH C
256141 PRESSURE SPRING A
281281 TRACK ROLLER D=16 B
281457 BUTTON BUFFER D=12 F=4 d=8 C
361004 CABLE GUIDE CFCC-4 ½" A
400002 CYL-SCR M3X6 DIN912 A
400026 CYL-SCR M4X12 A
400028 CYL-SCR M4X16 DIN912 A
420561 TORX SCREW M5x12 A
511006 LOCTITE 222 A
To Next Page
