Hamilton Microlab STAR - Insertion Guide Part List; Loading Tray Part List; Tip Waste Part List

Microlab
®
STAR Service Manual
12-43
12.6.12 Insertion Guide Part List
P/N Description SPC
173292 INSERTION GUIDE C
173293 STOP HOOK A
173299 SHEET METAL C
173300 DISK A
173729 INSERTION GUIDE - END C
173747 SPRING STRIP C
173843 LOAD DISPLAY BOARD B
400617 CYL-SCR M2.5X5 DIN912 A
403452 SUNK SCREW M3X6 DIN7991 A
12.6.13 Loading tray Part List
P/N Description SPC
173600 SLIDE BLOCK A
173602 SLIDE BLOCK WEDGE A
173700 HOLDER W OVAL BORE C
173701 HOLDER W ROUND BORE C
182112 REPLACEMENT TABLE RIGHT C
182113 REPLACEMENT TABLE LEFT C
400026 CYL-SCR M4X12 DIN912 A
403453 C-SUNK SCR M3X8 DIN7991 A
403453 SUNK SCR M3X8 DIN7991 A
408006 HEX NUT M4 DIN934 A
12.6.14 Tip Waste Part List
P/N Description SPC
173736 TIP WASTE CONTAINER C
173737 TIP WASTE LID C
173738 TIP WASTE HANDLE C
420561 TORX SCREW M5x12 A
