Hamilton Microlab STAR - Pipetting Arms X Drive Part List; Pipetting Channels Part List; Pipetting Head Part List

Microlab
®
STAR Service Manual
12-41
12.6.7 Pipetting Arm's X Drive Part List
P/N Description SPC
173380 OS-HOLDER C
173864 OS PIPETTING ARM – X-INIT A
182111 REPLACEMENT X-MOTOR B
250007 BALL BEARING ID= 8 AD=16/18 B=6 A
250045 BALL BEARING ID=15 AD=35 B=11 A
257056 SPACER PINS M5x20 I/O A
258129 COG BELT 10AT5/2875 A
258130 COG BELT 10T2.5/480 A
396011 MAGN. MEASURING TAPE B
400025 CYL-SCR M4X10 DIN912 A
400026 CYL-SCR M4X12 DIN912 A
400077 CYL-SCR M6X60 DIN912 C
400262 CYL-SCR M3X6 DIN912 A2 A
400302 CYL-SCR M4X8 DIN912 A2 A
405082 SET SCR M5X5 DIN913 A
413008 LOCK DISC 7 DIN6799 A
420561 TORX SCREW M5x12 A
12.6.8 Pipetting Channels Part List
P/N Description SPC
182103 Replacement Channel A A
182104 Replacement Channel B A
12.6.9 Pipetting Head Part List
P/N Description SPC
173330 TIP EJECTOR A
173332 STOP DISK A
173520 DISC 2 A
182105 REPLACE. PIPETTING HEAD 300ul A
182106 REPLACE. PIPETTING HEAD 1000ul A
254167 O-Ring ID3.6x1.45 A
400602 CYL-SCR M2x5 DIN912 A
400621 CYL-SCR M2.5x12 DIN912 A
409103 DISC M2 DIN125A A
511071 OMNI FIT 15M A
173310 GREASE 100 GR TOPAS AK50 A
