Microlab
®
STAR Service Manual
7-13
Covering of deck panels:
Instructions are the reverse of those for uncovering. Remember to guide Carrier
Sensor Board Cable through left deck panel first.
Guide deck panels as well as Carrier Stops into their positioning pins or holes as
required.
Attention: Do not bend sheet metal tongues of the Carrier Stops in the rear -
otherwise Carriers won't snap in correctly. See section 7.4.2.3 Replacement on
page 7-8.
Note: Start put Carrier Stops in place on Deck Panels, working from right to left.
Carefully connect them together so as to preserve them from any damage.
Plug in and fold Cable, remount cable cap and brush strip or docking station as the
case may be.
Attention: Do not push cable into whole of deck panel, due to avoid damage through
X-Arm drive.
