7-40
Removal
Attention: Never switch on ML STAR Instrument while cables such as those to
Autoload drive are not plugged in when replacing Autoload drive as short circuits are
possible.
Unscrew and remove:
182264 BLACK COVER LEFT
(Screws 2 x 403453)
and
182266 COVER LEFT
(Screws 4 x 403453).
Unscrew and remove:
182263 BLACK COVER RIGHT
(Screws 2 x 403453)
and
182274 COVER RIGHT
(Screws 4 x 403453).
