Microlab
®
STAR Service Manual
5-8
Packing the ML STAR Instrument (continued)
4. Put pipetting arm’s top housing in place.
5. With the pipetting arm’s front housing removed, push channel supporting
block towards the rear into the pipetting arm housing.
Then push it very carefully upwards to the channels.
