Microlab
®
STAR Service Manual
5-11
ML-STAR packaging (continued):
8. Place all accessories into the accessories boxes.
Accessories include:
• Wrapped loading trays and waste station.
• Carriers in their boxes
• Both spillage trays
Ensure no movement inside accessories boxes. Fill up empty space with crumpled paper, protection foam etc.
Then close accessories Box (use adhesive tape).
9. Place accessories boxes onto the Z-shaped blocks
Both Z-shaped blocks go onto instrument’s deck panel (left and right beside pipetting arm).
10. Square foam block placed above pipetting arm’s top cover serves as a buffer between the two accessory boxes.
11. Lower the packing surround from above onto instrument on pallet.
12. Place additional square foams between accessory boxes and cover of packing surround.
13. Place side panels left and right on top of both accessory boxes.
14. ML STAR IVD instrument’s back cover must also placed on top of the two accessory boxes.
Avoid scratches on panels and cover.
15. Close instrument packing surround with its top cover and tie up the crate securely.
