48
────────────────────────────────────────────────────
6.3 Measurement by External Control Terminal and External Output Terminal
────────────────────────────────────────────────────
【Input】
COMP
0to4
【State】
Comparator
number
2
1
2
3
1
3
H
L
【State】
Chuck
【Output】
NG
1
0
【Input】
TRIG
【Output】
H
L
【Output】
EOC
Hi,IN,Lo
1
0
1
0
Effective
FAST MEDIUM SLOW
Frequency: 50 Hz Approx.95 ms Approx.795 ms Approx.1.92 s
Frequency: 60 Hz Approx.80 ms Approx.660 ms Approx.1.60 s
(1) Selecting Comparator Number
When reselecting comparator number by external control terminal
signal, use COMP 0 to 4. After reselecting comparator number,
keep the same signal status.
Comparator number is reselected. Starts measurement after 3560
setting is stabilized.
(2) Measurement using trigger function
Connect object to be measured to measurement lead.
Measurement error signal(NG) is disengaged.
TRIG
―――――――――
signal is output after time to stabilize is reached.
Invalid when in free run status.
Waiting time（response time）is as follows depending on sampling.
This value applies in the case of pure resistance.
Waiting time varies depending on type of object to be measured.
Adjust it after measurement and when value fluctuates, enter
larger value.
Removes object to be measured
Outputs measurement error signal (NG). Repeats processes from .
