7.4 Message Reference
────────────────────────────────────────────────────
Synta
x
:CSET:VPARameter data1, data2
dat
a
Rang
e
(V)
data1 data1
5 -5.0000 to 5.000
0
-5.0000 to 5.000
0
50 -50.000 to 50.00
0
-50.000 to 50.00
0
*Numerical value dat
a
Exampl
e
Transmission
:CSET:VRAN 5;:VPAR 0.5000,3.5000
The comparator function executes
in the 5 V range under these
conditions: the upper limit is 3.5 V
and the lower limit is 0.5 V.
Synta
x
:CSET:VPARameter?
Respons
e
synta
x
(If headers are ON)
:CSET:VPARAMETER data1, data2
(If headers are OFF)
data1, data2
Exampl
e
(If headers are ON)
Transmission
:CSET:VPAR?
Response
:CSET:RPARAMETER 3.5000E+0,0.5000E+0
(If headers are OFF)
Transmission
:CSET:VPAR?
Response
3.5000E+0,0.5000E+0
F
unctio
n
This command sets the voltage rang
e
of the comparator specified by the
:CSET:NUMBer command. The upper
and lower limits are determined
automatically; the smaller value is
defined as the lower limit and the
larger value is defined as the upper
limit.
Note
s
･ If the set range deviates from the
range specified by the :CSET:VRANge
command, an execution error occurs
.
･ If resistance measurement mode ha
s
been selected by the :CSET:MODe
command for the comparator
specified by the :CSET:NUMBer
command, an execution error occurs
.
F
unctio
n
This command returns the set
voltage range of the comparator
specified by the :CSET:NUMBer
command in NR3 numeric data
(data) format.
Note
s
If resistance measurement mode ha
s
been selected by the :CSET:MODe
command for the comparator
specified by the :CSET:NUMBer
command, an execution error occurs
.
:CSET:VPARameter
■ Sets for the comparator voltage upper and lower limits.
:CSET:VPARameter?
■ Queries for the comparator voltage upper and lower limits.
