85
────────────────────────────────────────────────────
7.4 Message Reference
────────────────────────────────────────────────────
Synta
x
:MEASure:BATTery?
Respons
e
synta
x
(If headers are ON)
:MEASURE:BATTERY data1, data2
(If headers are OFF)
data1, data2
data1 Resistance
Resistance
range
(Ω)
Sampling rate
FAST MEDIUM/SLOW
30 m □□.□□E-3 □□.□□□E-3
300 m □□□.□E-3 □□□.□□E-3
3 □.□□□E+0 □.□□□□E+0
30 □□.□□E+0 □□.□□□E+0
300 □□□.□E+0 □□□.□□E+0
3k □.□□□E+3 □.□□□□E+3
OFF
1.0000E+8 1.0000E+8
NG
1.0000E+9 1.0000E+9
data2 Voltage
Voltage rang
e
(V)
All of sampling rate
5 ±□.□□□□E+0
50 ±□□.□□□E+0
OFF
±1.0000E+8
NG
1.0000E+9
data3 FAIL/PASS comparator results
OFF comparator isnot used
NG
Abnormal measurements
Exampl
e
(If headers are ON)
Transmission
:MEAS:BATT?
Response
:MEASURE:BATTERY 20.123E‑3,
3.5678E+0,PASS
(If headers are OFF)
Transmission
:MEAS:BATT?
Response
20.123E‑3,3.5678E+0,PASS
F
unctio
n
･ In resistance and voltage
measurement mode, this command
returns current measured
resistance and voltage in NR3
numeric data format (data1 and
data2) and the comparator result i
n
FAIL/PASS/OFF/NG character data
format (data3).
Note
s
If resistance measurement mode is
active, an execution error occurs.
:MEASure:BATTery?
■ Queries for the current measured resistance and voltage and comparator result.
