5.7 Status Data tab - IOM block
Modules - Status Data tab
The following information pertains to the Status Data tab for the following modules.
 ANALOG INPUT WITH HART
 ANALOG INPUT
 TC/RTD
 Analog Output
 Analog Output-HART
 DIGITAL INPUT 24VDC
 DIGITAL INPUT SEQUENCE OF EVENTS
 DIGITAL OUTPUT 24VDC
 DIGITAL INPUT PULSE ACCUMULATION
Prerequisites
 Control Builder is running
 A Series 8 I/O control module was created
Considerations
 All illustrations used in the procedure are for example purposes only.
The following is an example of a DIGITAL OUTPUT 24VDC Block Status Data tab.
