R500 Series 8 I/O User's Guide 275
April 2017 Honeywell
41 VREFFAIL
Reference voltage out of range
Diagnostic check:
Check reference voltage
Cause:
Internal 5V reference out of range in Analog Input or internal
AA55 reference test failed in the case of Digital Input.
Solution:
Replace the Analog Input or Digital Input IOM.
42 ADOUTUDF
Analog to digital conversion on this Analog Input channel is out of range.
Diagnostic check:
Check input wiring.
Cause:
Analog to digital conversion on this Analog Input channel is out
of range.
Solution:
Check the input wiring at the IOTA; possible open contact.
Otherwise, replace the IOM.
43 ADOUTCAL
Analog Input or Analog Output IOM is out of calibration.
Diagnostic check:
Check Analog Input or Analog Output IOM calibration
Cause:
Analog Input or Analog Output IOM is out of calibration.
Solution:
Calibrate or replace the IOM
44 BADFLREG
Analog Output module failure selection register is bad
Diagnostic check:
Cause:
Analog Output module failure selection register is bad
Solution:
45 BDSNDLTC
Secondary latch failure
