Chapter 5
Troubleshooting
LAN LEDs
131
LAN LEDs
There are front panel and rear panel LAN LEDs on the HP Integrity rx2620 server.
Front Panel LAN LEDs
The front panel LAN LED indicates the server is communicating over the Gigabit or server management
LAN:
• Blinking green, the server is communicating over the LAN.
• Solid green, LAN link is established, no current LAN activity.
Rear Panel LAN LEDs
There are two 1 Gb LAN ports on the rear panel. They are LAN A and LAN B.
LAN A Connector LEDs
The 1 Gb LAN A interface provides four LEDs on the rear panel. Table 5-23 details the LED locations and
states for the LAN A connector.
Table 5-23 Gb LAN A Connector LEDs
LAN LED Location Color State
Not used Top None None
1000mb 2nd from top Amber Blinking amber – the 1000 Mbps with
ethernet protocol and twisted-pair wiring is
enabled.
Off – no link.
100mb 2nd from bottom Green Blinking green – the 100 Mbps with
ethernet protocol and twisted-pair wiring is
enabled.
Off – no link.
Activity Bottom Green Blinking green – The Activity LED lights,
and all other LEDs are off for a 10 Mbps
connection.
Off – no activity
