Page #28 background image
Introduction
System Board Components
Chapter 1
28
1 Gb System LANs A and B
The 1 Gb system LAN ports A and B provide:
•Main server LANs
10/100/1000 Mb capability
USB Connectors
The USB connectors provide:
High speed 480 Mb/sec. capability
Full speed 12 Mb/sec. and low speed 1.5 Mb/sec
Support for USB keyboard and mouse
HP-UX supports HP USB keyboard and mouse
Data Pathing Information
Table 1-3 shows information about data pathing in the HP Integrity rx2620 server.
Table 1-3 Data Pathing - Part 1
PCI Slot PCI Card Function Physical Location ACPI Path
1 PCI-X 133 Mhz/64 bit Top slot (HWP0002,400)/PCI(1|0)
2 PCI-X 133 Mhz/64 bit 2nd from top (HWP0002,300)/PCI(1|0)
3 PCI-X 133 Mhz/64 bit 3rd from top (HWP0002,200)/PCI(1|0)
4 PCI-X 133 Mhz/64 bit Bottom slot (HWP0002,600)/PCI(1|0)
Core I/O -1 USB Port Rear bulkhead - “Mouse icon” (HWP0002,0)/PCI(1|0)/USB(0, 0)
Core I/O -2 USB Port Rear bulkhead - stacked top (HWP0002,0)/PCI(1|0)/USB(1, 0)
Core I/O -3 USB Port Rear bulkhead - “Kybd icon” (HWP0002,0)/PCI(1|1)/USB(0, 0)
Core I/O -4 USB Port Rear bulkhead - stacked bottom (HWP0002,0)/PCI(1|1)/USB(1, 0)
Core I/O -5 IDE Controller System board (HWP0002,0)/PCI(2|0)
Core I/O -6 1 Gb LAN Rear bulkhead - LAN Gb B (HWP0002,100)/PCI(3|0)
Core I/O -7 1 Gb LAN Rear bulkhead - LAN Gb A (HWP0002,0)/PCI(2|0)
Core I/O -8 SCSI - Channel A System board (HWP0002,100)/PCI(1|0)
Core I/O -9 SCSI - Channel A ID0 Bottom (#3) HDD (HWP0002,100)/PCI(1|0)/SCSI
(Pun0,Lun0)
Core I/O -10 SCSI - Channel A ID1 Middle (#2) HDD (HWP0002,100)/PCI(1|0)/SCSI
(Pun1,Lun0)
Core I/O -11 SCSI - Channel B System board (HWP0002,100)/PCI(1|1)
Core I/O -12 SCSI - Channel B ID2 Top (#1) HDD (HWP0002,100)/PCI(1|1)/SCSI
(Pun2, Lun0)
