Removing and Replacing Components
Removing and Replacing Internal Components
Chapter 4
78
Removing the System Battery
Step 1. Turn off the server and disconnect all cables.
Step 2. Remove the top metal cover. See “Removing and Replacing the Top Metal Cover” on page 50.
Step 3. Lift up on the battery and push on the back of it with a flat-head screwdriver to remove the battery
from its holder. See Figure 4-38 for the battery location on the system board.
CAUTION Only lift the battery high enough to clear the holder. Excessive stress on the battery
holder retaining clip may damage the clip.
Figure 4-38 Removing the System Battery
Front of server
