HP Integrity rx2620 User Manual

Introduction
Server Components
Chapter 1
19
Server Dimensions
Table 1-1 shows the dimensions and weight of the rx2620 server.
Server Components
The following components make up the HP Integrity rx2620 server.
Processor
• 1.4 GHz/12 MB L3 cache dual-core processor
• 1.6 GHz/18 MB L3 cache dual-core processor
Memory
• 12 memory DIMM slots
• 256 MB, 512 MB, 1 GB, 2 GB, and 4 GB standard 184 pins 2.5 V DDR1, CL2, registered, ECC
• 133 MHz memory bus frequency, 266 MTransfers/s data, 8.5 Gb/s peak data bandwidth
• Minimum memory size of 1 GB with four 256 MB DIMMs
• Maximum memory size of 32 GB with eight 4 GB DIMMs
• Upgrades must be made by quads of DIMMs
• DIMMs loaded by quads enable interleaved mode and chip spare
PCI Riser
• Four independent PCI-X 133 MHz 64 bit, 3.3 V, 15 W slots. There is no 5 V card and hot plug support
NOTE Some 25 W cards are supported. See the following slot matrix (by server):
http://www.docs.hp.com/en/SSM1-EL/slotmatrix.htm
For more information regarding specific I/O cards, see:
http://www.docs.hp.com/en/netcom.html
Table 1-1 Server Dimensions
Dimensions Value
Rack units 2U
Height 8.6 cm (3.4 in.)
Width 48.3 cm (19.0 in.)
Depth 67.9 cm (26.8 in.)
Weight
•Min
•Max
17.5 kg (38.6 lb.)
22.2 kg (49.0 lb.)
