HP Integrity rx2620 User Manual

Appendix C
Utilities
Using the Boot Configuration Menu
195
Boot From File
Use this option to manually run a specific application or driver.
NOTE This option boots the selected application or driver one time only. When you exit the
application, you return to this menu.
This option displays the file systems that are on your server or workstation and lets you browse these file
systems for applications or drivers that are executable. Executable files end with the .efi extension. You
can also select remote boot (LAN) options that have been configured on your network.
For example:
Boot From a File. Select a Volume
NO VOLUME LABEL [Acpi(HWP0002,0)/Pci(2|0)/Ata(Primary,Master)/CDROM
CD_FORMAT [Acpi(HWP0002,0)/Pci(2|0)/Ata(Secondary,Master)/CDROM
Removable Media Boot [Acpi(HWP0002,500)/Pci(2|0)/Ata(Secondary,Master)
Load File [EFI Shell [Built-in]]
Load File [Acpi(HWP0002,0)/Pci(3|0)/Mac(00306E4C4F1A)]
Exit
In this example:
• NO VOLUME LABEL is a hard drive. When you format a hard drive, the EFI tools provide an option to
LABEL the disk. In this example, the volume was not labelled.
• CD_FORMAT is the label created for the disk currently inside the DVD drive.
• Removable Media Boot allows you to boot from a removable media drive (CD/DVD drive). This option does
not support booting from a specific file on a specific removable media disc.
• The two Load Files are the EFI Shell and the LAN.
Add Boot Entry
Use this option to add items to the EFI boot menu.
3 PCI Acpi(HWP0002,200)/pci(1|0)
4 PCI Acpi(HWP0002,600)/pci(1|0)
Table C-4 HP Integrity rx2620 Drives
Drive Path
SCSI Disk (HDD1) Acpi(HWP0002,100)/Pci(1|1)/Scsi(Pun2,Lun0)
SCSI Disk (HDD2) Acpi(HWP0002,100)/Pci(1|0)/Scsi(Pun1,Lun0)
SCSI Disk (HDD3) Acpi(HWP0002,100)/Pci(1|0)/Scsi(Pun0,Lun0)
Removable Media Boot Acpi(HWP0002,0)/Pci(2|0)/ATA
Table C-3 HP Integrity rx2620 Slots (Continued)
Socket Path
