Appendix C
Utilities
Specifying SCSI Parameter
s
188
Using the SCSI Setup Utility
Step 1.
At the EFI shell prompt, type this command to ma
p the parameters for all PCI cards installed in
the server:
info io
A list of all the devices that are instal
led in the HP Integrity rx262
0 server and managed by EFI
drivers is displayed.
The output may look like this:
187
189
Table of Contents
Default Chapter
2
Legal Notices
2
Table of Contents
3
About this Document
13
Intended Audience
13
New and Changed Information in this Edition
13
Publishing History
13
Table 1 Publishing History Details
13
Document Organization
14
Typographic Conventions
14
HP-UX Release Name and Release Identifier
15
Related Documents
15
Table 2. HP-UX 11I Releases
15
HP Encourages Your Comments
16
1 Introduction
17
Server Overview
18
Figure 1-1. HP Integrity Rx2620 Server (Front View)
18
Figure 1-2. HP Integrity Rx2620 Server (Front View with Bezel Removed)
18
Figure 1-3. HP Integrity Rx2620 Server (Rear View)
18
Server Dimensions
19
Server Components
19
Processor
19
Memory
19
PCI Riser
19
Table 1-1. Server Dimensions
19
Internal Core I/O
20
External Core I/O
20
Power Supply Unit
20
System Board Manageability
20
Enhanced Server Manageability Using the Integrated Lights out Management Processor
20
Hard Disk Drives
21
System Board Components
22
Figure 1-4. System Block Diagram
22
Memory
23
Processor Bus
23
Processor Sockets
23
ZX1 I/O and Memory Controller
23
Figure 1-5. Memory Block Diagram
24
I/O Bus Interface
25
Table 1-2. Memory Array Capacities
25
Dual Serial Controller
26
Field Programmable Gate Array
26
Processor Dependent Hardware Controller
26
Baseboard Management Controller
27
IDE Interface
27
SCSI Controller
27
Data Pathing Information
28
Gb System Lans a and B
28
Table 1-3. Data Pathing - Part 1
28
USB Connectors
28
Table 1-4. Data Pathing - Part 2
29
Table 1-5. Data Pathing - Part 3
30
2 Controls, Ports, and Leds
31
Front Panel
32
Figure 2-1 Front View
32
Figure 2-2 Control Panel
32
Table 2-1. Control Panel Leds and Switches
33
Table 2-2 Power On/Off Button
33
Figure 2-3. Hot-Plug Disk Drive LED Indicators
34
Figure 2-4. Power Supply Leds
34
Hot-Plug Disk Drive Indicators
34
Table 2-3. Hard Disk Drive LED Definitions
34
Figure 2-5 DVD Leds
35
Table 2-4. Power Supply LED Definitions
35
Table 2-5. DVD Drive LED Definitions
35
Rear Panel
36
Figure 2-6 Rear View
36
Table 2-6. Rear Panel Connectors and Switches
36
Figure 2-7 10/100/1000 Base-T Ethernet Gb LAN a Connector Leds
38
LAN Gb a Connector
38
Table 2-7 10/100/1000 Base-T Ethernet Gb LAN a Connector Leds
38
Figure 2-8 10/100/1000 Base-T Ethernet Gb LAN B Connector Leds
39
LAN Gb B Connector
39
Table 2-8 10/100/1000 Base-T Ethernet Gb LAN B Connector Leds
39
Figure 2-9 Ilo MP LAN Leds
40
Management Processor LAN Leds (Optional)
40
Table 2-9 Ilo MP LAN Leds
40
3 Powering off and Powering on the Server
41
Power States
42
Powering off the Server
42
Powering off the Server Using the Ilo MP
42
Table 3-1 Power States
42
Powering off the Server Manually
43
Powering on the Server
43
Powering on the Server Using the Ilo MP
43
Powering on the Server Manually
44
4 Removing and Replacing Components
45
ESD Information
46
Service Tools Required
46
Location of Internal Components and Connectors
47
Table 4-1. Component Locations
47
Figure 4-1. Internal Physical Layout
47
Table 4-2. Connector Locations
48
Figure 4-2. System Board Connectors and Slots
48
Removing and Replacing System Top Metal Cover and Bezels
49
Rack-Mount System
49
Removing and Replacing the Top Metal Cover
50
Figure 4-3 Release the Rack Latches
50
Figure 4-4 Removing and Replacing the Top Metal Cover
51
Figure 4-5 Aligning the Top Metal Cover
51
Removing and Replacing the Front Bezel
52
Figure 4-6 Closing the Top Metal Cover
52
Figure 4-7 Front Bezel Retaining Clip
52
Removing and Replacing Hot-Swap and Hot-Plug Devices
53
Figure 4-8 Replacing the Front Bezel
53
Figure 4-9 Fan 1A or Fan 1B Removal
54
Removing and Replacing Server Fans
54
Figure 4-10 Fan 2 Removal
55
Figure 4-11 Fan 3 Removal
55
Figure 4-12 Releasing the Power Supply Retaining Clip
56
Removing and Replacing the Power Supply
56
Figure 4-13 Removing the Power Supply
57
Figure 4-14 Replacing the Power Supply
57
Removing and Replacing an Internal Hard Disk Drive
58
Figure 4-15 Unlocking the Disk Drive (if Necessary)
59
Figure 4-16 Releasing the Disk Drive
59
Figure 4-17 Removing the Disk Drive
60
Removing and Replacing Internal Components
61
Removing and Replacing Airflow Guides
61
Figure 4-18 Airflow Guides Locations
61
Removing and Replacing the Memory Airflow Guide
62
Removing and Replacing the Processor Airflow Guide
62
Figure 4-19 Removing the Memory Airflow Guide
62
Figure 4-20 Removing the Processor Airflow Guide
63
Figure 4-21 Open the Release Clip
63
Figure 4-22 Remove the Front Airflow Guide
64
Removing and Replacing Memory Dimms
65
Figure 4-23 DIMM Slot Identification
66
Removing and Replacing a Processor
68
Figure 4-24. Inserting DIMM into Slot
68
Figure 4-25. Processor Locations
69
Figure 4-26 Processor Location on System Board
70
Figure 4-27 Removing the Processor Airflow Guide
71
Figure 4-28 Unscrew the Captive Screws
71
Figure 4-29 Slide Sequencing Retainer Plate
72
Figure 4-30 Unlock Processor Module Locking Mechanism
73
Figure 4-31 Unlocked ZIF Socket Lock
74
Figure 4-32 Processor Alignment Pins
74
Figure 4-33 CPU Slot Alignment Holes
75
Figure 4-34 Installing the Processor Module
75
Figure 4-35 Locking the Processor Module in Place
76
Figure 4-36 Slide the Sequencing Retainer Plate
76
Removing and Replacing the System Battery
77
Figure 4-37 Secure the Captive Screws
77
Figure 4-38 Removing the System Battery
78
Removing and Replacing PCI Card Cage
79
Figure 4-39 Removing the PCI Cage
80
Figure 4-40 Removing the PCI Cage Cover
80
Removing and Replacing PCI Cards
81
Figure 4-41 Installing a PCI Slot Cover
82
Removing and Replacing the PCI Backplane
83
Figure 4-42 Installing a PCI Card
83
Figure 4-43 Removing the PCI Backplane
84
Figure 4-44 Replacing the PCI Backplane
84
Removing and Replacing a Removable Media Drive
85
Figure 4-45 Removable Media Drive Removal/Replacement
86
Removing and Replacing Ilo MP Hardware
87
Figure 4-46 Removing the Ilo MP Card
87
Figure 4-47 Replacing the Ilo MP Blank
88
Removing and Replacing the Ilo MP Battery
89
Figure 4-48 Removing the Ilo MP Battery
90
Removing and Replacing the LED Status Panel
91
Figure 4-49 Removing the LED Status Panel
91
Removing and Replacing the System Board
92
Figure 4-50 Remove System Board Mounting Screws
93
Figure 4-51 Remove the System Board Mounting Screw
93
Figure 4-52 Remove the System Board
94
Figure 4-53 Slide System Board into Chassis
94
Figure 4-54 Align the System Board PCI Connector
95
Figure 4-55 Slide System Board in Chassis
96
Figure 4-56 Install the Rear Panel Mounting Screws
96
Figure 4-57 Reinstall the Power Connectors
97
Removing and Replacing the Power Supply Interface Module
98
Figure 4-58 Power Cables and Holding Clips
99
Figure 4-59 Remove the Mounting Screw
99
Figure 4-60 Remove the PSI Interface Module
100
Figure 4-61 Replacing the Power Supply Interface Module
100
Removing and Replacing the Hard Disk Drive (SCSI) Backplane
101
Figure 4-62 Securing the Power Supply Interface Module and Cables
101
Figure 4-63 Open the Fan Power Bridge
102
Figure 4-64 Disconnect SCSI Cables
102
Figure 4-65 Remove Mounting Screws
103
Figure 4-66 Remove the SCSI Backplane
104
Figure 4-67 Remove the SCSI Backplane from Chassis
104
5 Troubleshooting
107
Troubleshooting Tips
108
Troubleshooting Methodology
108
Possible Problems
109
The System will Not Power-Up
109
The System will Not Boot
109
The System Has Intermittent Failures
110
The System LED or Diagnostic Leds Are Not on and no Error Messages Appear
111
The Server Powers off but Doesn't Restart
111
Troubleshooting and FRU Identification
113
Table 5-1. Problem Symptoms Repair Actions
113
Verifying Hard Disk Drive Operation
115
Figure 5-1 LED Apertures on Hard Disk Drive
115
Identifying and Diagnosing Hardware Problems
116
Power and System Leds
116
Table 5-2 System LED States
116
Table 5-3. Power and System LED States
120
Table 5-4. Diagnostic Leds Fault and Warning Categories
121
Figure 5-2. Diagnostic Leds
121
Table 5-5. Unknown Warning
122
Table 5-6. Memory Warnings
122
Table 5-7. System Board Warnings
123
Table 5-8 Fan Warnings
123
Table 5-9. Processor Warnings
124
Table 5-10. Temperature Warnings
124
Table 5-11. Video Warnings
124
Table 5-12. Power Supply Warnings
124
Table 5-13. Unknown Faults
125
Table 5-14 Memory Faults
125
Table 5-15. Firmware Errors
125
Table 5-16. System Board Faults
126
Table 5-17 Fan Faults
126
Table 5-18 Processor Faults
127
Table 5-19 BMC Faults
127
Table 5-20 Temperature Faults
127
Command Line Interface
128
Command Line Interface Menu
128
Table 5-21. Power Supply Errors
128
Troubleshooting Example Using CLI
129
System Board Diagnostic Leds
130
Table 5-22 System Board Leds
130
Figure 5-3 Location of the STBY, F/W and BMC Leds
130
LAN Leds
131
Front Panel LAN Leds
131
Rear Panel LAN Leds
131
Table 5-23. Gb LAN a Connector Leds
131
Optional Management Processor LAN Leds
132
Table 5-24. Gb LAN B Connector Leds
132
Table 5-25. Optional Management Processor LAN Leds
132
Diagnostics
133
Online Diagnostics/Exercisers
133
Offline Support Tool Availability
134
Offline Support Tools List
134
Table 5-26. Online Support Tools List
134
Table 5-27. Offline Support Tools List
134
General Diagnostic Tools
135
Fault Management Overview
135
HP-UX Fault Management
135
Table 5-28. General Diagnostic Tools List
135
Recommended Cleaning Procedures
136
Table 5-29 Cleaning
136
Where to Get Help
137
Information to Collect before You Contact Support
137
Online Support
137
Phone Support
138
Parts Information
139
Field Replaceable Parts View
140
Figure A-1 Parts Identification
140
Figure A-2 Tower Parts
141
Field Replaceable Parts List
142
Table A-1 Parts List
142
Booting the Operating System
147
Operating Systems Supported on HP Integrity Servers
148
Configuring System Boot Options
148
Booting and Shutting down HP-UX
149
Adding HP-UX to the Boot Options List
150
Standard HP-UX Booting
151
Single-User Mode HP-UX Booting
152
LVM Maintenance Mode HP-UX Booting
154
Shutting down HP-UX
154
Booting and Shutting down HP Openvms
155
Adding HP Openvms to the Boot Options List
155
Booting HP Openvms
156
Shutting down HP Openvms
158
Booting and Shutting down Microsoft Windows
159
Adding Microsoft Windows to the Boot Options List
159
Booting the Microsoft Windows Operating System
160
Shutting down Microsoft Windows
161
Booting and Shutting down Linux
163
Adding Linux to the Boot Options List
163
Booting the Red hat Enterprise Linux Operating System
164
Booting the Suse Linux Enterprise Server Operating System
165
Shutting down Linux
166
Utilities
167
Extensible Firmware Interface Boot Manager
168
EFI Commands
170
Table C-1 EFI Commands
170
EFI/POSSE Commands
172
Help
172
Help Bch Command
173
Help Command
173
Help Configuration Command
173
Help Cpuconfig Command
173
Baud
175
Table C-2 Communications Parameters
175
Boottest
176
Cpuconfig
177
Ioconfig
177
Default
178
Errdump
178
Info
179
Info Boot Command
184
Info Io Command
184
Lanaddress
185
Monarch
185
Pdt
186
Monarch Command
186
Pdt Clear Command
186
Pdt Command
186
Sysmode
187
Specifying SCSI Parameters
187
Using the SCSI Setup Utility
188
Using the Boot Configuration Menu
194
Paths
194
Table C-3 HP Integrity Rx2620 Slots
194
Table C-4. HP Integrity Rx2620 Drives
195
Table C-5 Console Output Devices
199
Table C-6 Console Output Devices
200
Table C-7 Console Output Devices
201
Using the System Configuration Menu
202
Table C-8 Console Output Devices
202
Using the Security Configuration Menu
203
Ilo MP
205
Configuring the Ilo MP LAN Port IP Address
206
Accessing the Ilo MP
207
Configuring the Ilo MP LAN Information
209
Ilo MP Command Reference
211
Table C-9 Ilo MP Main Menu Commands and Descriptions
211
Table C-10 Command Menu Commands and Descriptions
211
Index
213
Other manuals for HP Integrity rx2620
Read Me First
2 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the HP Integrity rx2620 and is the answer not in the manual?
Ask a question
HP Integrity rx2620 Specifications
General
Brand
HP
Model
Integrity rx2620
Category
Server
Language
English
Related product manuals
HP Integrity rx2660
249 pages
HP integrity rx2800 i4
156 pages
HP integrity rx2900 i4
156 pages
HP Integrity rx2800 - i2
151 pages
HP Integrity rx6600
348 pages
HP Integrity rx4640
232 pages
HP Integrity rx1620
136 pages
HP Integrity rx8640
45 pages
HP Integrity rx7640
101 pages
HP Integrity rx3600
11 pages
HP Integrity BL870c
229 pages
HP Integrity NonStop X NS7
97 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
