HP Integrity rx2620 User Manual

Introduction
System Board Components
Chapter 1
29
Core I/O -13 SCSI - Channel B Ext. Rear bulkhead - SCSI LVD/SE
connector
(HWP0002,100)/PCI(1|1)/SCSI
(Punx, Luny)
Core I/O -14 Internal IDE device Front DVD drive slot (HWP0002,0)/PCI(2|0)/ATA
Opt MP -1 MP Serial Controller Rear bulkhead - MP
Console/Remote/UPS conn.
(HWP0002,700)/PCI(1|0)
Opt MP -2 MP Console Controller Rear bulkhead - MP
Console/Remote/UPS conn.
HWP0002,700)/PCI(1|1)
Opt MP -3 MP VGA Controller Rear bulkhead - MP VGA conn. HWP0002,700)/PCI(2|0)
N/A System board Console
port (CLI)
Rear bulkhead - Serial
A/Console connector.
N/A
N/A System board Serial
port
Rear bulkhead - Serial B
connector
N/A
Table 1-4 Data Pathing - Part 2
PCI Slot MAPPER Path HP-UX Path Linux Path Windows Path
1 0/4/1/0 0/4/1/0 80:01.0
2 0/3/1/0 0/3/1/0 60:01.0
3 0/2/1/0 0/2/1/0 40:01.0
4 0/6/1/0 0/5/1/0 C0:01.0
Core I/O -1 0/0/1/0 0/0/1/0 00:01.0
Core I/O -2 0/0/1/0 0/0/1/0 00:01.0
Core I/O -3 0/0/1/1 0/0/1/1 00:01.1
Core I/O -4 0/0/1/1 0/0/1/1 00:01.1
Core I/O -5 0/0/2/0 0/0/2/0 00:02.0
Core I/O -6 0/0/3/0 0/0/3/0 00:03.0
Core I/O -7 0/1/2/0 0/1/2/0 20:02.0
Core I/O -8 0/1/1/0 0/1/1/0 20:01.0
Core I/O -9 0/1/1/0.0.0 0/1/1/0.0.0
Core I/O -10 0/1/1/0.1.0 0/1/1/0.1.0
Core I/O -11 0/1/1/1 0/1/1/1 20:01.1
Core I/O -12 0/1/1/1.2.0 0/1/1/1.2.0
Core I/O -13 0/1/1/1.x.y 0/1/1/1.x.y
Table 1-3 Data Pathing - Part 1 (Continued)
PCI Slot PCI Card Function Physical Location ACPI Path
