Removing and Replacing Components
Removing and Replacing Internal Components
Chapter 4
85
Step 4. Connect server power, PCI, and LAN cables.
Step 5. Power on the server. See “Powering On the Server” on page 43.
Step 6. Verify the installation of the PCI backplane:
• Check the LEDs of all PCI cards for proper operation.
• Run mapper from the Offline Diagnostics CD to insure that all PCI cards are identified.
• Monitor the SEL to ensure there are no events showing peripheral problems.
Removing and Replacing a Removable Media Drive
The removable media drive is located behind the front bezel.
WARNING Ensure that the server is powered-down and all power sources have been
disconnected from the server prior to removing or replacing a removable media
drive.
Voltages are present at various locations within the server whenever an AC power
source is connected. This voltage is present even when the main power switch is in
the off position.
Failure to observe this warning could result in personal injury or damage to
equipment.
CAUTION Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD
safety precautions could result in damage to the server. Failure to properly complete the steps
in this procedure will result in erratic server behavior or server failure. For assistance with this
procedure contact your local HP Authorized Service Provider.
Removing a Removable Media Drive
To remove a removable media drive, perform the following steps:
Step 1. Turn off the server and disconnect all cables. See “Powering Off the Server” on page 42.
Step 2. Remove the top metal cover. See “Removing and Replacing the Top Metal Cover” on page 50.
Step 3. Disconnect the IDE cable from the back of the drive. See Figure 4-45 for more information.
Step 4. Grasp the front of the DVD drive and squeeze in on the locking tab to release the drive.
Step 5. Pull the drive straight out to remove it from the chassis.
