Removing and Replacing Components
Removing and Replacing Hot-Swap and Hot-Plug Devices
Chapter 4
53
Step 2. Rotate the front panel outward and lift if away from the server chassis.
Replacing the Front Bezel
Step 1. Insert the bezel latches into the matching slots on the server chassis. See Figure 4-8 for more
information.
Step 2. Swing the bezel and push toward the front of the server until it locks into place.
Figure 4-8 Replacing the Front Bezel
Removing and Replacing Hot-Swap and Hot-Plug Devices
The HP Integrity rx2620 has hard disk drives that are hot-pluggable and power supplies and fans that are
hot-swappable. This section explains how to swap the following devices while the server is running:
•System fans
• Power supplies
• Hard drives
There is a significant difference between the terms hot-swap and hot-plug:
• Hot swapping happens at the device level. A hot-swappable device manages insertion or removal on its
own without assistance from operating system commands.
• Hot-plugging allows you to replace a defective component in a high-availability server while it is running.
However, hot-plugging may require interaction with the operating server to allow the removal and
replacement of a hot-plug device.
Front of server
