System Board Components
Chapter 1
30
Core I/O -14 0/0/2/0.0.0 0/0/2/0.0.0
Opt MP -1 0/7/1/0 0/6/1/0 E0:01.0
Opt MP -2 0/7/1/1 0/6/1/1 E0:01.1
Opt MP -3 0/7/2/0 0/6/2/0 E0:02.0
Table 1-5 Data Pathing - Part 3
PCI Slot
Rope
Number
ACPI
HID
ACPI
UID
PCI Bus
Address
PCI Bus
Number
PCI Host
Controller
Number
1 4/5 HWP0002 0x400 0x80-0xBF 4 4
2 3 HWP0002 0x300 0x60-0x7F 3 3
3 2 HWP0002 0x200 0x40-0x5F 2 2
4 6 HWP0002 0x600 0xC0-0xDF 6 5
Core I/O -1 0 HWP0002 0x000 0x00-0x1F 0 0
Core I/O -2 0 HWP0002 0x000 0x00-0x1F 0 0
Core I/O -3 0 HWP0002 0x000 0x00-0x1F 0 0
Core I/O -4 0 HWP0002 0x000 0x00-0x1F 0 0
Core I/O -5 0 HWP0002 0x000 0x00-0x1F 0 0
Core I/O -6 0 HWP0002 0x000 0x00-0x1F 0 0
Core I/O -7 1 HWP0002 0x100 0x20-0x3F 1 1
Core I/O -8 1 HWP0002 0x100 0x20-0x3F 1 1
Core I/O -9 1 HWP0002 0x100 0x20-0x3F 1 1
Core I/O -10 1 HWP0002 0x100 0x20-0x3F 1 1
Core I/O -11 1 HWP0002 0x100 0x20-0x3F 1 1
Core I/O -12 1 HWP0002 0x100 0x20-0x3F 1 1
Core I/O -13 1 HWP0002 0x100 0x20-0x3F 1 1
Core I/O -14 0 HWP0002 0x000 0x00-0x1F 0 0
Opt. MP -1 7 HWP0002 0x700 0xE0-0xFF N/A 7
Opt MP -2 7 HWP0002 0x700 0xE0-0xFF N/A 7
Opt MP -3 7 HWP0002 0x700 0xE0-0xFF N/A 7
